Heat Exchanger Inspection

STEAM GENERATOR AND CONDENSOR INSPECTION EQUIPMENT

Remote visual inspection of heat exchanger tubes requires large diameter, standard video probes or specifically designed rotating lateral vision probes.

Developed by EFER in lengths up to 30 m, probes responding to this application are summarized below:

• TUBE ASSEMBLIES WITH BENDS12 mm diameter JUMBOCAM probe

• TUBE ASSEMBLIES WITHOUT BENDS12 mm diameter JUMBOCAM probe

• Small diameter rotating lateral view TURN EXPLORATOR probe

• 28 mm diameter axial view CAM 28 EXPLORATOR probe

• 28 mm diameter rotating lateral view TURN 28 EXPLORATOR probe

• 28 mm diameter rotating double-view TWIN 28 EXPLORATOR probe

All probes are operated using a TIVE 900 unit and EXPLORATOR remote control, and can be stowed in the TR 30 operating reel.

The TWIN 28 EXPLORATOR probe provides the added advantage of allowing simultaneous rapid axial inspection and expert lateral viewing of tube inner surfaces.
